Beckhoff

Beckhoff EL9410

Beckhoff EL9410 Power Supply Unit Terminal

€70.00

Tip

Beckhoff EP1008-0001

Beckhoff EP1008-0001 EtherCAT Box, 8-channel digital input, 24 V DC, 3 ms, M8

€30.00

Tip

Beckhoff EP1018-0001

Beckhoff EP1018-0001 EtherCAT Box, 8-channel digital input, 24 V DC, 10 µs, M8

€60.00

Beckhoff EP2316-0008

Beckhoff EP2316-0008 | EtherCAT Box, 8-channel digital input + 8-channel digital output, 24 V DC, 10 µs, 0.5 A, D-sub The EP2316-0008 EtherCAT Box combines eight digital inputs (upper socket connector) and eight digital outputs (lower socket connector) in a single device. The inputs have a filter of 10 µs. The outputs process load currents up to 0.5 A and are short-circuit-proof and protected against reverse polarity. The signal status is displayed via the optional plug connector. The signal connection is made via spring-cage connectors, optionally available in 1- and 3-pole versions. The module is delivered without connectors. The supply of the connected sensors is done by an internal, short-circuit proof driver module with a total of 0.5 A for all sensors. The outputs are supplied via flush mounted. All outputs are short-circuit-proof and protected against reverse polarity. The 16-channel design offers a very high channel density in a very small space. Technical dataEP2316-0008ProtocolEtherCATBus interface2 x M8 socket, shielded, screw typeSpecificationEN 61131-2, type 1/3Number of channels8 inputs + 8 outputsInput/output connectionsD-sub socket, 25-pin, UNC4-40Input filter10 µs“0” signal voltage-3…+5 V“1” signal voltage11…30 V, 6 mA input current (EN 61131-2, type 3)Sensor supplyfrom control voltage, max. 0.5 A, short-circuit proof in totalLoad typeohmic, inductive, lamp loadRated load voltage24 V DC (-15 %/+20 %)Max. output current0.5 A per channel, individually short-circuit proofShort-circuit currenttyp. 1.5 AAuxiliary power currenttyp. 20 mA + loadCurrent consumption from US120 mAPower supply connectionfeed: 1 x M8 male socket, 4-pin; downstream connection: 1 x M8 female socket, 4-pinElectrical isolation500 VSpecial featuresideal for high number of channelsWeightapprox. 165 gOperating/storage temperature-25…+60 °C/-40…+85 °CVibration/shock resistanceconforms to EN 60068-2-6/EN 60068-2-27EMC immunity/emissionconforms to EN 61000-6-2/EN 61000-6-4Approvals/markingsCE, ULProtect. rating/installation pos.IP65/66/67 (conforms to EN 60529)/variable

€40.00
